H Series Face & Entrance Smart Locks for OEM Projects
Compare ten H-series entrance models with face, camera or narrow-panel configurations. Confirm model-specific access, door fit, power and optional functions.
10 models to compare · Samples and customization confirmed by model
How to select h series: face & entrance locks
The H Series chapter groups ten entrance-door models with different hardware and access configurations. H-03, H-18, H-21, H-22, H-23 and H-68 list 3D face recognition. H-01, H-05 and H-09 use lever formats with basic or camera configurations, while H-08 is a narrow aluminum-door model. This chapter membership does not make their mechanisms or functions equivalent. Start with the door drawing and required access workflow, then confirm the exact version and evaluate a sample.
Model and optional access
Check which face, fingerprint, camera and optional palm-vein functions the selected model actually lists; confirm enrollment behavior and capacity.
Door and panel compatibility
Compare model-specific panel dimensions, door construction, lock body, handing and mounting preparation. Confirm the narrow profile requirements for H-08.
Power and video configuration
Confirm the supplied battery, selected basic or camera version, display details and app/network requirements before writing installation and support materials.
Compare h series: face & entrance locks
Open a model for its specifications, source catalogue and available options. App configuration, door fit and customization vary by model.
Face recognition · Catalogue model
H-03 3D Face Recognition Smart Lock
3D face-recognition model with 20 face groups, an indoor HD display and a 4200 mAh battery specification for residential door-fit and sample evaluation.
- App option
- Tuya (Wi-Fi; confirm configuration). Select one configuration; availability must be confirmed.
- Power
- 4200 mAh battery (chemistry to be confirmed)
- Door thickness
- 40–120 mm
Face recognition · Catalogue model
H-18 3D Face Recognition Smart Lock
A 439 mm 3D face model with a video-intercom configuration and optional palm-vein recognition; select the biometric and network version before sampling.
- App option
- Tuya (Wi-Fi; confirm configuration). Select one configuration; availability must be confirmed.
- Power
- 4200 mAh battery (chemistry to be confirmed)
- Door thickness
- 40–120 mm
Face recognition · Catalogue model
H-21 3D Face Recognition Smart Lock
CNC-engraved 3D face model with a 439 × 70 mm format and optional palm-vein recognition, offering a distinct panel specification for brand evaluation.
- App option
- Tuya (Wi-Fi; confirm configuration). Select one configuration; availability must be confirmed.
- Power
- 4200 mAh battery (chemistry to be confirmed)
- Door thickness
- 40–120 mm
Face recognition · Catalogue model
H-22 3D Face Recognition Smart Lock
A 440 mm 3D face model with an indoor HD display, video-intercom configuration and optional palm-vein access for residential OEM projects.
- App option
- Tuya (Wi-Fi; confirm configuration). Select one configuration; availability must be confirmed.
- Power
- 4200 mAh battery (chemistry to be confirmed)
- Door thickness
- 40–120 mm
Face recognition · Catalogue model
H-23 3D Face Recognition Smart Lock
CNC-engraved 420 mm face-recognition model with 20 face groups and optional palm-vein access; confirm the final biometric and video configuration.
- App option
- Tuya (Wi-Fi; confirm configuration). Select one configuration; availability must be confirmed.
- Power
- 4200 mAh battery (chemistry to be confirmed)
- Door thickness
- 40–120 mm
Face recognition · Catalogue model
H-68 3D Face Recognition Smart Lock
A 460 mm 3D face-recognition model with a wide-angle camera, indoor HD display and a 4200 mAh battery specification for residential project sourcing.
- App option
- Tuya (Wi-Fi; confirm configuration). Select one configuration; availability must be confirmed.
- Power
- 4200 mAh battery (chemistry to be confirmed)
- Door thickness
- 40–120 mm
Lever · Catalogue model
H-01 Lever Smart Lock
A 368 mm fingerprint lever model with basic and camera configurations shown separately; confirm the indoor display and Tuya setup on the chosen version.
- App option
- Basic configuration / Camera configuration / Tuya (Wi-Fi; confirm configuration). Select one configuration; availability must be confirmed.
- Power
- Alkaline dry batteries (size and quantity to be confirmed)
- Door thickness
- 40–120 mm
Lever · Catalogue model
H-05 Lever Smart Lock
Aluminum lever model with a 390 mm panel and alkaline dry-battery power; basic and camera configurations provide different project selections.
- App option
- Basic configuration / Camera configuration / Tuya (Wi-Fi; confirm configuration). Select one configuration; availability must be confirmed.
- Power
- Alkaline dry batteries (size and quantity to be confirmed)
- Door thickness
- 40–120 mm
Lever · Catalogue model
H-09 Lever Smart Lock
A 390 mm fingerprint lever model with catalogue-listed finish choices and basic or camera configurations; confirm display and app functions before ordering.
- App option
- Basic configuration / Camera configuration / Tuya (Wi-Fi; confirm configuration). Select one configuration; availability must be confirmed.
- Power
- Alkaline dry batteries (size and quantity to be confirmed)
- Door thickness
- 40–120 mm
Aluminum door · Catalogue model
H-08 Aluminum Door Smart Lock
Narrow 36 mm lever panel from the thermal-break aluminum-door series; confirm the stile, lock body, battery compartment and camera configuration for the installation.
- App option
- Basic configuration / Camera configuration / Tuya (Wi-Fi; confirm configuration). Select one configuration; availability must be confirmed.
- Power
- Alkaline dry batteries (size and quantity to be confirmed)
- Door thickness
- 40–120 mm
Download the complete 2026 catalogue
Each model page links to its catalogue reference. Confirm the chosen version, installation details and document requirements before sample approval.
H Series: Face & Entrance Locks: buyer questions
Do all H-series models have face recognition or automatic locking?
No. The chapter contains face-recognition, lever and narrow aluminum-door formats. Read the selected model's technical type and access list. Catalogue chapter membership does not establish a motorized mechanism or a shared biometric configuration.
Does H-08's aluminum-door positioning establish an outdoor rating?
No. Confirm the intended door profile, mounting arrangement and environmental suitability. The H-08 record does not supply a water-resistance rating or supporting test documentation, so request evidence for the proposed installation.
Discuss your private label or project requirement
Send your target market, door photographs and measurements, preferred model, app version and quantity. GwayLock can review model fit, sample options and OEM/ODM requirements before quotation.
